Food corrugated carton semi-automatic two pieces carton box folder gluer machine

1 Set
MOQ
$15,900.00(1 - 1 Sets) $15,500.00(>=2 Sets)
Prix
Food corrugated carton semi-automatic two pieces carton box folder gluer machine
traits Galerie Description de produit Demandez une citation
traits
Caractéristiques
Type: Gluing Machine
Applicable Industries: Manufacturing Plant, Food & Beverage Factory
Showroom Location: None
Condition: New
Application: Food, Beverage, Commodity, Medical, Chemical, Machinery & Hardware, APPAREL, Textiles
Packaging Type: Film, case
Packaging Material: Plastic, Metal, Wood
Automatic Grade: Semi-automatic
Driven Type: Electric
Voltage: 220V/380V/440V
Dimension(L*W*H): 3400*3500*1300mm
Weight: about 2.3 ton
Warranty: 1 Year
Key Selling Points: High Productivity
After Warranty Service: Video technical support, Online support, Spare parts, Field maintenance and repair service
Local Service Location: None
After-sales Service Provided: Free spare parts, Field installation, commissioning and training, Field maintenance and repair service, Video technical support, Online support
Certification: CE & ISO
Name: Semi-auto folder gluer machine
Max Sheet size: 1250*1200mm
Min Sheet size: 450*320mm
Speed: 0-2000pcs/h
Power: 6.6KW
Box forming: Two Pieces Gluing
Glue type: Cold and hot melt
Advantages: 4 servo motor
Folding way: Manual Fold
Feed stype: Servo motor automatic
Informations de base
Certification: CE & ISO
Conditions de paiement et expédition
Packaging Details: plastic film and wooden box
Supply Ability: 240 Set/Sets per Year
Description de produit

Corrugated cardboard semi-auto two pieces carton box folder gluer machine

Product Description

Technology Parameters

Model

SPHX-2000A

SPHX-2000B

SPHX-2500A

SPHX-2500B

Sheet size(mm)

Max1000×800,

Min450×320

Max 1000×1200,

Min 450×320

Max 1250×800,

Min 450×320

Max 1250×1200,

Min 450×320

Speed

0-2000pcs/h

0-2000pcs/h

0-2000pcs/h

0-2000pcs/h

Dimension

3400*3150*1340

3400*3550*1340

3900*3150*1340

3900*3550*1340

Power

6.6kw

6.6kw

6.6kw

6.6kw

High speed semi-auto folder gluer suit for AA, AB two piece box and single piece box. It instead manual glue, reduce labor intensity. Machine Features: high degree of automatic, reduce labour, improve product quality and effective, reduce work cost. Only need two workers operate it, one worker feed sheet and collect finished boxes, another worker fold and rectify boxes. Reduce space for machine. Working range of sheet: A-E flute.

Machine adopt double variable-frequency motor, PLC centralize control, drive and control precision.

High-power adsorption device for feed system, feed single and double piece of sheet. Independ servo motor for left and right feed wheel for double pieces sheet feeding. When sheet to out place stop feed.

When make two piece box, sheets can be glued during feed( hot-melt glue in the middle), three side pneumatic fix position, top pneumatic press, two piece sheets adhesive to one, glue firmly.

Press part is final set. After glue to one-piece fold by manual and rectify problem of line and flute cross. Go to press belt to finish product.

Spare list

Main parts list

Item

Specification

Qty(set)

Original/brand

Main motor

0.75KW

1

Huicheng

Press motor

0.4KW

1

Huicheng

Glue motor

120W 250W

2

Oute

Blow

2.2KW

2

Shanghai

Bearing

SKF

LM shaft

Shunyang, Tianjin

Belt

Xibeike

Detailed Images

Application

Related Products
FAQ

Q:1.Are you a manufacturer, trading company or a third party?

A:We are a manufacturer, located in Mahai industrial area south of Dongguang county, Hebei province, China. Warmly welcome to visit our company.

Q:2. What is your minimum order quantity, can you send me samples?

A:Our minimum quantity is 1 set, as our product is machinery equipment, it’s difficult to send you samples, if you have any questions about the products, please feel free to contact us for more detail, we are glad to provide you more information such as specifications, video, etc.

Q:3. How does your factory do regarding quality controlling?

A:(1) All raw material we used are environmental-friendly.

(2) Skillful workers care every details in handling the producing and packing process.

(3) Quality control department are specially responsible for quality in each process.

We have been kept providing high quality products by introducing advanced technologies for over 20 years, and our products are also widely exported to many different countries including Russia, the Middle East, Africa, Southeast Asia, EU, etc, which earned us a high reputation among the customers.

Q:4.What is the delivery time of your machine?

A:In general, the delivery time of our machine is about 30 days, customized machine will be delivered as the negotiation with our clients.

Q:5.How about the after-sale service?

A:(1) TM online for 24 hours, also contact by email, skype, MSN, whatsapp, etc.

(2) To solve the problems with videos/pictures.

(3) One year warranty for spare parts change.

If you meet any other questions, please feel free to contact us.
